How Prompt Engineering is Transforming Hardware Security with LLMs

In the rapidly evolving world of cybersecurity, innovation is increasingly being driven by artificial intelligence. While software security has long been a major focus, hardware-level security—especially during the design and verification stages—remains a challenging frontier. The industry faces a persistent issue: a lack of reference datasets containing known security vulnerabilities, making it difficult to test and train detection tools effectively.

A recent research initiative from the University of Florida, Gainesville offers a creative and potentially game-changing solution. Presented at the 2024 IEEE Hardware-Oriented Security and Trust Conference, the paper introduces SecRT-LLM — a novel framework that uses Large Language Models (LLMs) like GPT-3.5 and structured prompt engineering to generate and detect vulnerabilities in digital hardware designs, particularly Finite State Machines (FSMs).

The Innovation: Prompt Engineering for Vulnerability Injection and Detection

The study centers on the creation of Vul-FSM, a dataset of 10,000 Verilog FSM designs, each embedded with at least one of 16 different security weaknesses. These vulnerabilities are drawn from widely accepted frameworks such as the CWE-MITRE database. The dataset was created by systematically injecting flaws into a clean set of 400 base FSM designs using prompt-engineered LLM workflows.

The framework, SecRT-LLM, doesn’t stop at generation. It also includes an LLM-based detection system capable of identifying vulnerabilities in the dataset with impressive accuracy — achieving ~80% accuracy on first attempts and up to ~99% within five tries. Both the benchmark dataset and detection tool aim to serve as open resources for the verification and EDA communities.

Why This Matters: Addressing a Long-Standing Gap in Hardware Security

In hardware design, security vulnerabilities are often overlooked until late in the development lifecycle. Tools that could proactively catch such flaws are limited by one major issue: the absence of labeled, real-world benchmarks.

As Paul Cunningham, GM of Verification at Cadence, points out:

"Hardware security verification is still a niche market today, but it is clearly on the rise. Availability of good benchmark suites with known vulnerabilities is limited, which in turn limits our ability to develop effective EDA tools."

By automating the generation and annotation of vulnerable designs using LLMs, this research provides the training ground needed to enhance modern verification tools — bridging the gap between AI capabilities and real-world design validation.

Inside the Technique: Structured Prompt Engineering

What sets this approach apart is the sophistication of the prompt engineering strategies used to guide the LLMs. The authors define six specialized prompt structures that significantly boost the quality, accuracy, and usefulness of the generated designs:

1. Reflexive Verification Prompting – Encourages the LLM to audit and verify its own outputs.

2. Sequential Integration Prompting – Breaks down the problem into sub-tasks via a chain-of-thought method.

3. Exemplary Demonstration Prompting – Uses example solutions to guide the LLM’s response formatting.

4. Contextual Security Prompting – Focuses on embedding and identifying security flaws tied to CWE classes.

5. Focused Assessment Prompting – Directs the model’s attention to specific security-related design components.

6. Structured Data Prompting – Formats outputs systematically for ease of downstream processing and analysis.

An example shown in the research (Figure 6) illustrates how a prompt is broken down into sections with instructions, verification checks, and illustrative examples — effectively training the LLM in real time to produce high-quality, vulnerability-rich RTL designs.

Expert Commentary: Industry Reflections

Raúl Camposano, entrepreneur and former Synopsys CTO, highlights the practical implications:

"The paper introduces a strong integration of prompt engineering, LLM inference, and fidelity checking. These strategies greatly improve performance in both generating and detecting hardware security vulnerabilities."

He emphasizes that commercial verification tools still rarely integrate AI for these tasks — something SecRT-LLM could help change. Today’s commercial security tools focus on threat modeling, formal methods, and static checks, but rarely extend into AI-assisted vulnerability generation or detection at the RTL level.

This research demonstrates that AI can now meaningfully contribute to hardware security, potentially influencing future commercial EDA tools and methodologies.

Industry Implications: A Glimpse into the Future of AI-Powered Verification

By providing a robust, labeled dataset and a scalable method for vulnerability detection, this research serves multiple industry needs:

• EDA Companies can use Vul-FSM to improve and train verification tools.

• Chip Designers gain access to automated testing systems that reduce manual effort and time.

• Security Analysts benefit from AI-assisted detection at the hardware design level, a stage often overlooked.

• Academia and Startups now have an open benchmark to experiment with and improve upon.

In a time when hardware attacks and side-channel vulnerabilities are becoming more sophisticated, such AI-powered verification workflows will play an increasingly critical role in safeguarding the chip supply chain.

Final Thoughts

This isn’t just another application of generative AI — it’s a purpose-driven integration of prompt engineering, machine learning, and security awareness at one of the most foundational levels of digital design. With increasing complexity in chips, especially in AI, automotive, and IoT applications, the ability to automate vulnerability testing and detection could become a critical standard.

SecRT-LLM stands as a compelling example of how we can use LLMs not only to innovate but to protect. As more organizations explore AI-driven EDA workflows, this work could become a blueprint for the future of hardware security verification.
